Computer-on-Modules

Computer-on-modules, with help coordinating carrier-board requirements and manufacturer technical resources.

Request a quote Contact us

Models and configurations

Explore models, then compare their listed configurations. We can help confirm the configuration, pricing and availability for your application.

Plan a system from your requirements

Find a model or part number

Manufacturer Processor Form factor / system type Maximum memory (GB) to

More specifications

Data LAN portstoMemory typeProcessor family

9 models · 4 listed configurations · 3 additional part numbers

AAEON COM-RAPC6, module perspective

AAEONCOM Express Type 6 Compact

COM-RAPC6

A compact COM Express Type 6 module with Intel processing and DDR5 memory support for integration with a suitable carrier board.

CPU options: Intel Core i7-13800HE / Intel Core i3-1320PE / Intel Processor U300E / Intel Core i7-13800HRE
Memory: Up to 64 GB · DDR5 SO-DIMM
Key connections: 2.5GbE Intel I226-IT interface through carrier

Compare 4 listed configurations

Specifications below belong to each listed part number. Confirm pricing and availability with Edge.

COM-RAPC6-A10-0001

Processor: Intel Core i7-13800HE
Memory data rate (MT/s): Up to 5200
Operating minimum (°C): 0
Operating maximum (°C): 60

Full specifications

COM-RAPC6-A10-0003

Processor: Intel Core i3-1320PE
Memory data rate (MT/s): Up to 5200
Operating minimum (°C): 0
Operating maximum (°C): 60

Full specifications

COM-RAPC6-A10-0005

Processor: Intel Processor U300E
Memory data rate (MT/s): Up to 4800
Operating minimum (°C): 0
Operating maximum (°C): 60

Full specifications

COM-RAPC6W2-A10-0001

Processor: Intel Core i7-13800HRE
Memory data rate (MT/s): Up to 5200
Operating minimum (°C): -40
Operating maximum (°C): 85

Full specifications

AM1808 SoM-M1, product view 1

Beacon EmbeddedWorksSystem-on-module

AM1808 SoM-M1

System-on-module based on Texas Instruments Sitara AM1808 processor with an ARM926EJ-S core running at 450 MHz. Review carrier-board, memory and interface requirements with us.

Processor: The AM1808 SoM-M1 supports the Texas Instruments Sitara AM1808 processor with an ARM926EJ-S core running at 450 MHz
Memory: Scalable serial NOR flash memory (16 MB standard); Mobile DDR SDRAM memory (64 or 128 MB); Boots from NOR flash
Key connections: 10/100 Base-T Ethernet controller

AM3517 SoM-M2, product view 1

Beacon EmbeddedWorksSystem-on-module

AM3517 SoM-M2

System-on-module based on Texas Instruments Sitara AM3517 microprocessor with ARM Cortex-A8 RISC core running at 600 MHz. Review carrier-board, memory and interface requirements with us.

Processor: The AM3517 SOM-M2 supports the Texas Instruments Sitara AM3517 microprocessor with ARM Cortex-A8 RISC core running at 600 MHz
Memory: Scalable NAND flash memory (512 MB standard); Boots from onboard NAND or external SD/MMC, NAND, NOR, UART, USB, or Ethernet; 166 MHz DDR2 SDRAM, 256 MB standard (scalable to 512MB)

DM3730 / AM3703 SoM-LV, product view 1

Beacon EmbeddedWorksSystem-on-module

DM3730 / AM3703 SoM-LV

System-on-module based on Texas Instruments DM3730 or AM3703 Applications Processor running up to 1 GHz. The SOM supports the following Texas Instruments processors: DaVinci DM3730 Sitara AM3703; IVA2.2 Subsystem TMS320C64x+™ DSP core running up to 800 MHz and supporting multiple codecs (DM3730 only); POWER SGX™ Graphics Accelerator (DM3730 only). Review carrier-board, memory and interface requirements with us.

Processor: Texas Instruments DM3730 or AM3703 Applications Processor running up to 1 GHz. The SOM supports the following Texas Instruments processors: DaVinci DM3730 Sitara AM3703; IVA2.2 Subsystem TMS320C64x+™ DSP core running up to 800 MHz and supporting multiple codecs (DM3730 only); POWER SGX™ Graphics Accelerator (DM3730 only)
Memory: NOR flash memory (16 MB standard); Mobile DDR SDRAM / NAND flash memory (PoP technology) 256 MB / 512 MB
Key connections: 10/100 Base-T Ethernet controller (application/debug); 802.11b/g/n wireless Ethernet; Bluetooth 2.1 + EDR

i.MX6 SoM-M3, product view 1

Beacon EmbeddedWorksSystem-on-module

i.MX6 SoM-M3

System-on-module based on NXP i.MX6 single-, dual-, or quad-core ARM® Cortex™-A9 processor running up to 1GHz (single) or 1.2 GHz (dual/quad). Review carrier-board, memory and interface requirements with us.

Processor: NXP i.MX6 single-, dual-, or quad-core ARM® Cortex™-A9 processor running up to 1GHz (single) or 1.2 GHz (dual/quad)
Memory: 32-bit wide DDR3L-1066, 2 GB (dual/quad); NAND flash, 1 GB

Inflexion™ Zynq 7020 SoM-LV, product view 1

Beacon EmbeddedWorksSystem-on-module

Inflexion™ Zynq 7020 SoM-LV

System-on-module based on Xilinx Zynq™ Z-7020 All Programmable SoC featuring dual-core ARM® Cortex™-A9 processing system running up to 766 MHz with Artix™-7 FPGA programmable logic fabric. Review carrier-board, memory and interface requirements with us.

Processor: Xilinx Zynq™ Z-7020 All Programmable SoC featuring dual-core ARM® Cortex™-A9 processing system running up to 766 MHz with Artix™-7 FPGA programmable logic fabric
Memory: 32-bit wide LPDDR2-800 (512 MB); QPSI Flash (32MB)

OMAP-L138 SoM-M1, product view 1

Beacon EmbeddedWorksSystem-on-module

OMAP-L138 SoM-M1

System-on-module based on following Texas Instruments processors: OMAP-L138 processor with dual core ARM926EJ-S and C6748 VLIW digital signal processor (DSP) running at 375 MHz ( link to Texas Instruments OMAP-L138 page ) TMS320C6748 VLIW DSP running at 375 MHz ( link to Texas Instruments TMS320C6748 page ). Review carrier-board, memory and interface requirements with us.

Processor: The OMAP-L138 SoM-M1 supports the following Texas Instruments processors: OMAP-L138 processor with dual core ARM926EJ-S and C6748 VLIW digital signal processor (DSP) running at 375 MHz ( link to Texas Instruments OMAP-L138 page ) TMS320C6748 VLIW DSP running at 375 MHz ( link to Texas Instruments TMS320C6748 page )
Memory: Scalable serial NOR flash memory (16 MB standard); Boots from NOR flash; Mobile DDR SDRAM memory, 64 or 128 MB
Key connections: 10/100 Base-T Ethernet controller

OMAP35x SoM-LV, product view 1

Beacon EmbeddedWorksSystem-on-module

OMAP35x SoM-LV

Processor module for integration with a carrier board. Review processor, memory and interface requirements with us.

Processor: Texas Instruments OMAP35x™ Applications Processor running up to 600 MHz*. The SOM supports the following Texas Instruments processors: OMAP3503 ( link to Texas Instruments OMAP3503 page ) OMAP3530 ( link to Texas Instruments OMAP3530 page ); IVA2.2 Subsystem TMS320C64x™ DSP core running up to 430 MHz and supporting multiple codecs (only supported on OMAP3530 processor).
Memory: Scalable NOR flash memory (16 MB standard); Mobile DDR SDRAM / NAND flash memory (PoP technology) 256 MB / 512 MB (standard SOM); Boots from NAND flash or external SD card

OMAP35x Torpedo™ SoM, product view 1

Beacon EmbeddedWorksSystem-on-module

OMAP35x Torpedo™ SoM

System-on-module based on Texas Instruments OMAP35x Applications Processor running up to 600 MHz*. The SOM supports the following Texas Instruments processors: OMAP3503 OMAP3530; IVA2.2 Subsystem TMS320C64x™ DSP core running up to 430 MHz and supporting multiple codecs (only supported on OMAP3530 processor). Review carrier-board, memory and interface requirements with us.

Processor: Texas Instruments OMAP35x Applications Processor running up to 600 MHz*. The SOM supports the following Texas Instruments processors: OMAP3503 OMAP3530; IVA2.2 Subsystem TMS320C64x™ DSP core running up to 430 MHz and supporting multiple codecs (only supported on OMAP3530 processor).
Memory: Mobile DDR SDRAM / NAND flash memory (PoP technology) 128 MB / 256 MB (kit SOM) 256 MB / 512 MB (standard SOM); Boots from NAND flash or external SD card

Additional part numbers

These listed parts have their own product details.

ADLINK

EXPRESS-KLE-E3-1505M V6

Basic Com Express Type6 module Intel Xeon E3-1505M v6 process 3.0/4.0 GHz with CM238 chipset

ADLINK

LEC-IMX62-C7-1G-4G-ER

SMARC Short Size Module with Freescale i.MX6, Dual, 1GB RAM, 4GB eMMC, Rev A6 PCB

Beacon EmbeddedWorks

SDK-IMX8MPQ-10-6G32GR

Zoom i.MX 8M Plus Development
