System-on-module
Beacon EmbeddedWorks AM1808 SoM-M1
System-on-module based on Texas Instruments Sitara AM1808 processor with an ARM926EJ-S core running at 450 MHz. Review carrier-board, memory and interface requirements with us.
Contact Edge to confirm the exact ordering number and configuration for your application.
At a glance
AM1808 SoM-M1 platform details
- Platform
- System-on-module
- Processor / supported family
- The AM1808 SoM-M1 supports the Texas Instruments Sitara AM1808 processor with an ARM926EJ-S core running at 450 MHz
- Ethernet specification
- 10/100 Base-T Ethernet controller
- Software and Tools
- Open source Linux Board Support Package (available from Texas Instruments); Linux SDKs; U-Boot (bootloader/monitor)
- Memory options
- Scalable serial NOR flash memory (16 MB standard); Mobile DDR SDRAM memory (64 or 128 MB); Boots from NOR flash
- USB
- One USB 2.0 high-speed On-the-Go interface; One USB 1.1 full-speed host interface
- Serial I/O
- Three external UARTs; Two I2Cs
- Display
- Programmable color LCD controller supports up to a 16 bpp TFT interface; Integrated 4-wire touchscreen controller (TPS65070)
Product photographs
Technical specifications
AM1808 SoM-M1 common specifications
- PC Card Expansion
- Serial ATA Controller: SATA 1.5 & 3.0 Gpbs support; MMC/SD card support
Ratings and included hardware depend on the selected configuration. Confirm application requirements with Edge.
Lifecycle status changes. Confirm current status and the roadmap with us before you qualify.
