Tianma · P Series

P0700WVF1MA10

Diagonal
7 in
Resolution · WVGA
800 × 480
Brightness
1,000 nits
Interface
LVDS

SFT panel rated for −30 to 80 °C operation.

Request a quote
Request datasheet
Authorized Tianma distributor Tianma America Distributor of the Year, 2025
P0700WVF1MA10 product photo

Specifications

Display & optics

Diagonal size
7 in
Resolution
800 × 480
Resolution name
WVGA
Brightness
1,000 nits
Contrast ratio
1000:1
Display mode
SFT
Technology
a-Si
Viewing angle
85/85/85/85
Response time
25 ms
Aspect ratio
5:3

Integration & physical details

Interface
LVDS
Touch
Not included · Factory PCAP optional
LED driver built in
Yes
Backlight lifetime
70,000 h
Operating temperature
−30 to 80 °C
Outline dimensions
169.80 × 109.70 × 8.9 mm
Active area
152.4 × 91.44 mm
Grade
Advanced
Description

7.0" WVGA, Advanced, LVDS, SFT, 1000 nits, -30+80C 70K hr w/ LED Dr

Documents

Request
Datasheet, mechanical drawing and pinoutRequest from us

Request pricing and availabilityP0700WVF1MA10

Please don’t include sensitive or confidential information in this form. Privacy notice

Loading form…

What information should I leave out?

Do not submit classified information, Controlled Unclassified Information (CUI), export-controlled technical data, payment-card information, Social Security numbers, health information, passwords, or other sensitive data through this form. Contact Edge to discuss an appropriate transfer method.

We provide available lot-level traceability and manufacturer documentation for authorized-channel parts.

Send the quantity and your target date. We'll come back with pricing and availability.

Open the form

For documentation, pricing and availability: 800.647.3343.

Edge Electronics · Product summary
Tianma · P0700WVF1MA10 · P Series

https://www.edgeelectronics.com/p/tianma-p0700wvf1ma10/

Confirm specifications for the required revision with Edge or the manufacturer. For documentation, pricing and availability: 800.647.3343.
