HX-4096
Manufacturer part number: 4175501XX-3
Harsh-environment True 4K LCD and OLED controller, conformal coated. HDMI 2.0 and DisplayPort 1.2 inputs; V-by-One, eDP, and LVDS outputs.
In stock.
Authorized Digital View distributor
Specifications
Application & availability
- Target applications
- Digital signage, Corporate AV, Medical, Industrial, Harsh environments, Marine, Transportation, Kiosks & retail
Video & display
- Input interfaces
- HDMI, DisplayPort, DVI
- Video inputs and versions
- HDMI 2.0, HDMI 1.4, DisplayPort 1.2, DVI-I
- Maximum video input resolution
- 4096 × 2160
- Maximum video input refresh rate
- 60 Hz
- Panel interface
- V-by-One, eDP, LVDS
- Panel output details
- V-by-One, eDP, LVDS dual
- Supported resolutions
- Up to 4096 × 2160
- Color depth (bits per color)
- 10
- Image processing
- scaling, PiP, PbP-quad
- Published latency
- 15 ms
Integration & physical details
- Control interfaces
- OSD buttons, IR remote, RS-232, Ethernet, DDC/CI
- Audio output
- digital audio line-out (from header), OSD volume control
- Backlight control
- onboard LED driver (up to 4 LED strings, max 50V total; current 90-150mA); inverter via CNB1 with VESA DPMS enable; analog/PWM brightness (100-440Hz) via serial/OSD
- Panel supply options
- 3.3V, 5V, 10V, 12V, 18V
- Supply voltage
- 12 or 24 V DC
- Power consumption (board only)
- 10 W
- Environment grade
- Harsh
- Operating temperature
- −40 to 80 °C
- Board dimensions
- 203.2 × 154 mm (L x W)
- Board height
- 18.93 mm
