Supermicro · Gold configuration
SYS-212GB-FNR-01-G2
A 2U configuration with two 96GB GPUs for AI model serving, agents, and retrieval-augmented generation.
- Included processor
- 1 × Intel Xeon 6731P
- Installed GPU
- 2 × NVIDIA RTX PRO 6000 Blackwell Server Edition
- Installed memory
- 512GB DDR5-6400
Authorized Supermicro distributor
Included in this Gold configuration
- Form factor / system type
- 2U rackmount
- Included processor
- 1 × Intel Xeon 6731P
- Installed GPU
- 2 × NVIDIA RTX PRO 6000 Blackwell Server Edition
- GPU memory per installed device (GB)
- 96
- Installed memory
- 512GB DDR5-6400
- Storage configuration
- 2 × 3.84TB E1.S SSD; 1 × 960GB M.2 NVMe SSD
- Ethernet specification
- Dual 10GbE RJ45
- Included power equipment
- 2 × 2700W Titanium power supplies
Memory ratings describe the modules; operating speed depends on the CPU and DIMM configuration.
Platform capabilities and installation requirements
- Supported GPU capacity
- Up to 4 double-width GPUs; supported options depend on the platform configuration.
- Supported memory capacity
- Up to 1TB DDR5 RDIMM at 6400MT/s (1DPC); up to 512GB MRDIMM at 8000MT/s (1DPC); up to 2TB RDIMM at 5200MT/s (2DPC).
- Enclosure dimensions (W × H × D)
- 438.4 × 87 × 900mm
- Cooling
- 5 × 8cm heavy-duty fans
- Operating temperature
- 10 to 35 °C
- Management networking
- Dedicated 1GbE BMC port; separate from the two data ports.
Documents
PDFProduct datasheetSupermicro PDF
↓ Request pricing and availabilitySYS-212GB-FNR-01-G2
We provide available lot-level traceability and manufacturer documentation for authorized-channel parts.
Send the quantity and your target date. We'll come back with pricing and availability.
Open the formFor documentation, pricing and availability: 800.647.3343.
